Rubber Profile
OSE-P 30 58 00
VITECTOR
Measuring Tools & Sensors
58 mm (2.28"), Clips Foot, None, 30 mm (1.18"), , 17 mm, EPDM
Available
0
General Data Height 58 mm (2.28") Foot Clips Foot Sealing Lip None Width 30 mm (1.18") Foot Width 17 mm Material EPDM Applicable Bumper OSE-B 5518 Finger Detection Yes Hardness 65 ± 5 Shore A Operation Temperature +5 °C to +55 °C (41 °F to 131 °F) Weight 0.6 kg/m Dead Surface Region 80 mm Roll Length 50 m (164 ft) Unit of Measure Meter Product Life Cycle Established
Compatible Bumpers Product Height Width OSE-B 5518 55 mm (2.17") 18 mm (0.71")
Compatible Retainers Product Width Inside Width Outside ALU-3009 26 mm (1.02") 30 mm (1.18")
All dimension in [inch] mm. This drawing and the information contained is for general presentation purposes only. Please refer to the "Download" section for detailed technical drawings.
